Plastic Film Pulse Jet Cloth Bag Filter Rotary Airlock Valve Working Principle

Plastic Film Pulse Jet Cloth Bag Filter Rotary Airlock Valve Working Principle

    • Plastic Film Pulse Jet Cloth Bag Filter Rotary Airlock Valve Working Principle
  • Plastic Film Pulse Jet Cloth Bag Filter Rotary Airlock Valve Working Principle

    جزئیات محصول:

    Place of Origin: CHINA
    نام تجاری: YIBU
    گواهی: CE / UL / SGS / EAC / CR – TU
    Model Number: MC

    پرداخت:

    Minimum Order Quantity: 1 set
    قیمت: Negotiation
    Packaging Details: Woodencase
    Delivery Time: 6weeks
    Payment Terms: L/C, T/T
    Supply Ability: 20 SETS PER MONTH
    مخاطب
    توضیحات محصول جزئیات
    Metal: SUS304 SUS316 , CS Filter class: Customized
    Capacity: 10000-100000cube meter /h Bag size: φ120*3000
    Temp: 120-300℃ Size: Customized
    برجسته:

    industrial dust collector

    ,

    pulse jet dust collector

    SUS304 SUS316L Plastic film Pulse Dust filter with cloth bag 10μm for chemical industry , food industry



    MCSeries Pulse Dust filter with cloth bag (bag filter)



    Product Description

    On the basis of MC-I, we develop the MC- II Square shape pulse cloth bag filter.

    Except the features that it has high efficiency dust collecting, big capacity of air rate, stable performance, and it is easy to operate and maintain. Compared with MC-I, the usage of MC-II is better, for example: MC is not easy to let the powder stay, and it has wide applications. It is widely used in the ventilation, dust removing and powder restoration in the grain, food, feed, metallurgical, chemical, building material, medical and other industries.

    Application

    It is used for different dryer, mixer, granulator or relative machine to remove the dust.

    The type of installation



    type of installation

    Plastic Film Pulse Jet Cloth Bag Filter Rotary Airlock Valve Working Principle 0



    Product parameters







    Schematic of installation

    Plastic Film Pulse Jet Cloth Bag Filter Rotary Airlock Valve Working Principle 1

    Main Dimension

    parameterspec MC24 MC36 MC48 MC60 MC72 MC84 MC96 MC120
    A 1000 1400 1800 2200 2600 3000 3560 4360
    B 1450
    C 780 1180 1600 2000 2400 1400+1400 1670+1670 2080+2080
    D 1230
    E 3700 3850 4100
    F 3500 3600 3850
    G 1700 1750 2000
    H 3040 3090 3300
    a 476 576 876 876 1076 676 776 876
    b 336 376
    c 400 500 800 800 1000 600×2 700×1 800×2
    d 260 300 300×2
    e 576 576 876 876 1076 1276 1326 1436
    f 276 376
    g 500 500 800 800 1000 1200 1250 1360
    h 200 300
    k1×n1
    k1×2
    110×4
    =440
    108×5
    =540
    120×7
    =840
    120×7
    =840
    120×7+100×2
    =1040
    110×4+100×2
    =640
    110×5+95×2
    =740
    120×7
    =840
    k2×n2 150×2=300 113.3×3=340
    k3×n3
    k3×2
    108×5
    =540
    108×5
    =540
    120×7
    =840
    120×7
    =840
    120×7+
    100×2
    =1040
    124×10
    =1240
    120×9+
    105×2
    =1290
    120×10+
    100×2
    =1400
    k4×n4 120×2=240 113.3×3=340
    Dia .of the flange at the dust discharge port 150 150 150 150 150 200 200 200
